This is a timed quiz. You will be given 1200 seconds to answer all questions. Are you ready?
1200
The peak to peak value of 40 V sine wave is:
Correct! Wrong!
A resultant current is made of two components: a 10 A d.c. component and a sinusoidal component of maximum value 14.14 A. The RMS value of the resultant current is โ amperes.
Correct! Wrong!
A complex current wave is given by i = 5 + 5 sin 100 ฯt ampere. Its average value is โ ampere.
Correct! Wrong!
If e1 = A sin ฯt and e2 = B sin (ฯt โ ฯ), then
Correct! Wrong!
Advertisement
The period of 1 kHz a.c is :
Correct! Wrong!
A hot wire ammeter reads 10 A in an ac circuit. The peak value of current is:
Correct! Wrong!
The r.m.s. value of a half-wave rectified current is 10A, its value for full-wave rectification would be โ amperes.
Correct! Wrong!
As sine wave has a frequency of 50 Hz. Its angular frequency is โ radian/second.
Correct! Wrong!
Advertisement
An a.c. current given by i = 14.14 sin (ฯt + ฯ/6) has an r.m.s value of โ amperes.
Correct! Wrong!
Hot-wire ammeters are used for measuring:
Correct! Wrong!
What is the peak to peak value for 120 V ac?
Correct! Wrong!
A sinusoidal current has a peak value of 8.5 A. What value of direct current has the same heating effect?
Correct! Wrong!
Advertisement
The r.m.s. value of sinusoidal a.c. current is equal to its value at an angle of โ degree
Correct! Wrong!
If a phasor points straight down, its angle can be ggiven as 270 degree or
Correct! Wrong!
An a.c. current given by i = 14.14 sin (ฯt +ฯ/6) has and a phase of โ degrees.
Correct! Wrong!
AC Fundamentals Quiz
your marks ๐
Need Improvement
Your Marks
Good Marks
Your Marks
Excellent ๐
Share your Results:
